SPECIFICATIONS
| PowerTrain | ||
| Engine | ||
| Model | OM 926 | |
| Maximum Power, kW | 210 kW @ 2200 rpm | |
| Maximum Torque, Nm | 1100 Nm @ 1200 - 1600 rpm | |
| No. of Cylinders, Displacement (CC) | June 1, 7200 | |
| Emission Compliance | Bharat Stage VI | |
| Gearbox | ||
| Gearbox Model & Type | G 131, 9F+1R, Mechanical, Synchromesh Gears | |
| Clutch Type | Single Dry Plate, Hydraulic Control | |
| Clutch Diameter (mm) | 430, 4.5 mm High Wear | |
| Power Take- Off | Gearbox PTO Spline - Optional | |
| Axle | ||
| Front Axle Model, Type | IF 7.0 | |
| Rear Axle Model, Type | RA1: IRT390-11, RA2: IRT390-11 | |
| Rear Axle Ratio* | 4.778 | |
| Dimensions (mm): All Dimensions are for CBC | ||
| Wheel Base (mm): | 3975 | |
| Loading Span (ft)/ Loadbody cpc (Cu.m): | NA | |
| Overall Length (mm): | 6935 | |
| Overall Width (mm): | 2490 | |
| Overall Height (mm) (CBC): | 2910 | |
| Front Overhang (mm): | 1485 | |
| Rear Overhang (mm): | 800 | |
| Minimum Ground Clearance (mm): | 255 | |
| Weight | ||
| Gross Combination Weight | (with Suitable Three Axle Trailer) Radial (11R20); Radial (295/90R20) & Tubeless (295/80R22) Tyres - 54960 kgs; 55000 kgs & 55000 kgs | |
| Chassis Frame, Suspension & Tyres | ||
| Frame Section (DxWxT) (mm) | 288 x 70 x 9 | |
| Front Suspension | Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers | |
| Rear Suspension | Bogie Suspension | |
| Anti Roll Bar | Standard on Front Axle | |
| Brakes & Tyres | ||
| Service Brake | Pneumatic, Foot Operated, Dual Line with ABS | |
| Parking Brake | Pneumatically Operated Hand Control Valve | |
| Front Axle Brake | Ø 410 drum | |
| Rear Axle Brake | Ø 410 drum | |
| Tyre Size | Radial Tyres (11R20 or 295/90R20) & Tubeless Tyres (295/80R22.5) | |
| Steering & Cabin | ||
| Steering Type | Hydraulic Power Assisted | |
| Cabin: | Sleeper | |
| Fuel Tank & Electricals | ||
| Fuel Tank/ Filling Capacity | 455L/ 430L | |
| Adblue Tank/ Filling Capacity | 60L/ 51L | |
| Voltage | 24V | |
| Battery Capacity | 120Ah | |
| Performance | ||
| Maximum Gradeability % | 0.236 | |
| Maximum Geared Speed | 80 kmph | |
| Turning Circle Diameter (TCD)* | 16.7 m | |
