SPECIFICATIONS
Powertrain | ||
Engine | ||
Model | OM 926 | |
Maximum Power, kW | 210 kW @ 2200 rpm | |
Maximum Torque, Nm | 1100 Nm @ 1200 - 1600 rpm | |
No. of Cylinders, Displacement (CC) | 6, 7200 | |
Emission Compliance | Bharat Stage VI | |
Gearbox | ||
Gearbox Model & Type | G 131, 8F+1R, Mechanical, Synchromesh Gears | |
Clutch Type | Single Dry Plate, Hydraulic Control | |
Clutch Diameter (mm) | 430 mm, 4.5 mm | |
Axle | ||
Front Axle Model, Type | IF 7.0 | |
Rear Axle Model, Type | RA1 : RS440 + RA2 : IT-14 | |
Rear Axle Ratio* | 4.3 | |
Dimensions (mm): All Dimensions are for CBC | ||
Wheel Base (mm) | 6575 | |
Loading Span (ft)/ Loadbody cpc (Cu.m) | 30.3 ft | |
Overall Length (mm) | 11492 | |
Overall Width (mm) | 2490 | |
Overall Height (mm) (CBC) | 2985 | |
Front Overhang (mm) | 1485 | |
Rear Overhang (mm) | 2757 | |
Minimum Ground Clearance (mm) | 178 | |
Weight | ||
Gross Vehicle Weight | 47500 kgs | |
Chassis Frame, Suspension & Tyres | ||
Frame Section (DxWxT) (mm) | 286 x 70 x 8 | |
Front Suspension | Parabolic Leaf Spring | |
Rear Suspension | New Parabolic Bogie | |
Anti Roll Bar | Standard on Front Axle and rear axle RA2 | |
Brakes & Tyres | ||
Service Brake | Pneumatic, Foot Operated, Dual Line with ABS | |
Parking Brake | Pneumatically Operated Hand Control Valve | |
Front Axle Brake | Ø 410 drum | |
Rear Axle Brake | Ø 410 drum | |
Tyre Size | Radial Tyres (Front- Rib & Rear - Lug) - 295/90R20 Tubeless Tyres (Front- Rib & Rear - Lug) - 295/80R22.5 | |
Steering & Cabin | ||
Steering Type | Hydraulic Power Assisted | |
Cabin | Mid Cabin | |
Fuel Tank & Electricals | ||
Fuel Tank/ Filling Capacity | 330L/310L | |
Adblue Tank/ Filling Capacity | 60L /51L | |
Voltage | 24V | |
Battery Capacity | 120Ah | |
Performance | ||
Maximum Gradeability % | 26.8% | |
Maximum Geared Speed | 80 kmph | |
Turning Circle Diameter (TCD)* | 24 m |
